VICTRON ENERGY Multi RS 230V
Inverter/chargers

Multi RS 230V

SKU principal: PMR482604000

Multi RS 230V

<p class="MsoNormal" style="background-image: initial; background-position: initial; background-size: initial; background-repeat: initial; background-attachment: initial; background-origin: initial; background-clip: initial;">The Multi RS 48/6000 is a lightweight,
high-frequency 48V/6kVA inverter/charger suitable for both stationary and mobile applications. It is the non-solar variant of our Multi RS Solar,
and does not include built-in solar charge controllers.</p><p class="MsoNormal" style="background-image: initial; background-position: initial; background-size: initial; background-repeat: initial; background-attachment: initial; background-origin: initial; background-clip: initial;">For stationary applications,
it supports Dynamic ESS functionality while giving you the flexibility to pair it with a different type or size of solar inverter. It can also be used as a direct grid connection without batteries,
making it easy to start simple and add storage later.</p><p class="MsoNormal" style="background-image: initial; background-position: initial; background-size: initial; background-repeat: initial; background-attachment: initial; background-origin: initial; background-clip: initial;">For mobile applications,
the Multi RS offers a lightweight solution that keeps the batteries fully charged,
and when excess energy is available,
it can feed that energy back into the grid.</p><p class="Titelalinea"> </p><p class="MsoNormal" style="background-image: initial; background-position: initial; background-size: initial; background-repeat: initial; background-attachment: initial; background-origin: initial; background-clip: initial;">Monitor all parameters via the integrated display or the VictronConnect app,
which also provides historical trend data,
quick firmware updates,
and easy configuration tools. Connect to a Cerbo GX for advanced ESS functions,
including zero-export to prevent grid feed-in and backup mode to power critical loads during outages.<o:p></o:p></p>

Códigos SKU

PMR482604000
DATOS DEL FABRICANTE

Especificaciones técnicas

Power Control
1
Power Assist
1
Parallel Operation
Three Phase Operation
1
Number Ac Inputs
1
Transfer Switch Current Rating
50 A
Battery Voltage Nominal
48 V
D C Input Voltage Range
[ 38, 62 ] V
A C Output Voltage
230 V
Maximum Cont Inv Current
25 A
Frequency
50
Cont Power V A25
6, 000 VA
Cont Power W25A
4, 600 W
Cont Power W25B
5, 200 W
Cont Power W40
4, 500 W
Cont Power W65
3, 000 W
Peak Power Rating3S
9, 000 W
Peak Power Rating4M
7, 000 W
Short Circuit Current
45 A
Max Efficiency
96.5 %
Zero Load Power
20 W
Low Battery Shutdown
37.2 V
Low Battery Restart
43.6 V
Mppt Operating Voltage Range
[ -∞, +∞ ] V
Charge Voltage Range
[ 36, 60 ] V
Charge Voltage Absorption
57.6 V
Charge Voltage Float
55.2 V
Maximum Battery Charge Current
88 A
Battery Temperature Sensor
Included
Battery Voltage Sense
1
Programmable Relay
DC rating: 4A up to 35VDC and 1A up to 70VDC
Protections
Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output
Communication Port
VE.Direct, VE.Can, Bluetooth
Bluetooth
Yes, -4dBm, 2402 – 2480 MHz
Communication Port General
Yes, 2x
Remote On Off
1
Fully Programmable Ports
1
Operating Temp Range
[ -40, 65 ] °C
Fan Assist Cooling
1
Max Altitude
2, 000 m
Max Humidity
95 %
Max Ac Input Current
50 A
A C Input Voltage Range
[ 187, 265 ] VAC
A C Input Frequency Range
[ 45, 65 ] Hz
Pollution Degree
2
Auxiliary Output
1
Number Ac Outputs
2
A C Connection Terminal Type
Screw terminals 10 mm² (8 AWG)
Battery Connection
M8 bolts
Colour
Blue (RAL 5012) and Black (RAL 9017)
Material
Steel
Protection Category
IP21
Weight
11.2 kg
Height
462 mm
Width
425 mm
Depth
127 mm
Safety
EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2, IEC 62040, IEC 62477
Emission Immunity
EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
