MultiPlus-II

SKU principal: PMP482505010

MultiPlus-II

<p>The MultiPlus-II is a multifunctional inverter/charger with two AC outputs. Suitable for professional marine,
yachting,
vehicle,
and land-based off-grid systems,
it also provides the isolation and redundancy required for ESS setups. PowerControl allows the MultiPlus-II to prevent grid or generator overload,
while PowerAssist boosts AC power during peak demand. In the event of an outage,
the inverter switches over in milliseconds,
keeping computers and sensitive electronics running without interruption. The battery charger combines speed with efficiency through a smart adaptive algorithm that extends battery life. Ready for expansion,
the MultiPlus-II supports parallel and three-phase configurations when a system needs to scale. </p><p>Note: for a short period of time this product was called MultiGrid-II.</p>

Códigos SKU

PMP482505010 PMP482305010 PMP242305010 PMP482305100 PMP482805000 PMP122305010 PMP483105000 PMP242505010 PMP122305110 PMP122305120 PMP242305100 PMP483150000 PMP122305122 PMP482305102 PMP482305012 PMP482505012 PMP242305102 PMP482505110 PMP122505010 PMP242505110 PMP122505012 PMP482405012 PMP482605012 PMP482505300 PMP482505120 PMP122405010 PMP122405100

DATOS DEL FABRICANTE

Especificaciones técnicas

Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 100 A
Max Ac Input Current: 100 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 10, 000 VA
Cont Power W25: 8, 000 W
Cont Power W40: 7, 000 W
Cont Power W65: 6, 000 W
Peak Power Rating: 18, 000 W
Max App Feedin Power: 10, 000 VA
Max Efficiency: 96 %
Zero Load Power: 38 W
Zero Load Power A E S: 27 W
Zero Load Power Search: 4 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 140 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: M6 bolts
Battery Connection Terminal Type: M8 bolts (two for positive and two for negative connection)
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 49 kg
Height: 677 mm
Width: 363 mm
Depth: 206 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 100 A
Max Ac Input Current: 100 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 15, 000 VA
Cont Power W25: 12, 000 W
Cont Power W40: 10, 000 W
Cont Power W65: 7, 000 W
Peak Power Rating: 27, 000 W
Max App Feedin Power: 15, 000 VA
Max Efficiency: 95 %
Zero Load Power: 55 W
Zero Load Power A E S: 39 W
Zero Load Power Search: 6 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 200 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: M6 bolts
Battery Connection Terminal Type: M8 bolts (two for positive and two for negative connection)
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 80 kg
Height: 810 mm
Width: 405 mm
Depth: 217 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max App Feedin Power: 5, 000 VA
Max Efficiency: 96 %
Zero Load Power: 18 W
Zero Load Power A E S: 12 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 30 kg
Height: 565 mm
Width: 320 mm
Depth: 149 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max App Feedin Power: 3, 000 VA
Max Efficiency: 95 %
Zero Load Power: 11 W
Zero Load Power A E S: 7 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 35 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 499 mm
Width: 268 mm
Depth: 141 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max App Feedin Power: 3, 000 VA
Max Efficiency: 95 %
Zero Load Power: 11 W
Zero Load Power A E S: 7 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 35 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 499 mm
Width: 268 mm
Depth: 141 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max App Feedin Power: 5, 000 VA
Max Efficiency: 96 %
Zero Load Power: 18 W
Zero Load Power A E S: 12 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 30 kg
Height: 565 mm
Width: 320 mm
Depth: 149 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max App Feedin Power: 5, 000 VA
Max Efficiency: 95 %
Zero Load Power: 15 W
Zero Load Power A E S: 11 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 220 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 33 kg
Height: 702 mm
Width: 345 mm
Depth: 152 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 24 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 19, 33 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max App Feedin Power: 5, 000 VA
Max Efficiency: 96 %
Zero Load Power: 18 W
Zero Load Power A E S: 12 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 28.8 VDC
Charge Voltage Float: 26.6 VDC
Charge Voltage Storage: 26.4 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 30 kg
Height: 607 mm
Width: 330 mm
Depth: 149 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 93 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 578 mm
Width: 277 mm
Depth: 148 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 458
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 24 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 19, 33 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 94 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 28.8 VDC
Charge Voltage Float: 27.6 VDC
Charge Voltage Storage: 26.4 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 536 mm
Width: 277 mm
Depth: 147 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 458
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 24 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 95 A
Max Ac Input Current: 95 A
D C Input Voltage Range: [ 19, 33 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max Efficiency: 95 %
Zero Load Power: 24 W
Zero Load Power A E S: 10 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 28.8 VDC
Charge Voltage Float: 27.6 VDC
Charge Voltage Storage: 26.4 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 35 mm² (2 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 29 kg
Height: 627 mm
Width: 350 mm
Depth: 150 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
A C Input Voltage Range1: [ 187, 265 ] VAC
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 36, 60 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Short Name: 6k5
Cont Power W25: 6, 000 W
Cont Power W40: 5, 700 W
Cont Power W65: 4, 600 W
Peak Power Rating: 11, 000 W
Max App Feedin Power: 6, 000 W
Max Efficiency: 96 %
Zero Load Power: 28 W
Zero Load Power A E S: 18 W
Zero Load Power Search: 8 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Maximum Battery Charge Current: 100 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP21
Weight: 29 kg
Height: 644 mm
Width: 320 mm
Depth: 150 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
A C Input Voltage Range1: [ 187, 265 ] VAC
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 36, 60 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Short Name: 4k5
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 7, 000 W
Max App Feedin Power: 4, 000 W
Max Efficiency: 95 %
Zero Load Power: 20 W
Zero Load Power A E S: 13 W
Zero Load Power Search: 8 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 55 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP21
Weight: 22 kg
Height: 590 mm
Width: 275 mm
Depth: 149 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Frequency Select: 50Hz or 60Hz
Transfer Switch Current Rating: 95 A
Max Ac Input Current: 95 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max Efficiency: 96 %
Zero Load Power: 15 W
Zero Load Power A E S: 10 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 60 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 35 mm² (2 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 32 kg
Height: 536 mm
Width: 277 mm
Depth: 147 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, CSA C22.2 107.1-16
Emission Immunity: EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 24 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 19, 33 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max App Feedin Power: 3, 000 VA
Max Efficiency: 94 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 28.8 VDC
Charge Voltage Float: 27.6 VDC
Charge Voltage Storage: 26.4 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 499 mm
Width: 268 mm
Depth: 141 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max App Feedin Power: 5, 000 VA
Max Efficiency: 95 %
Zero Load Power: 15 W
Zero Load Power A E S: 11 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 220 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 33 kg
Height: 702 mm
Width: 345 mm
Depth: 152 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 95 %
Zero Load Power: 11 W
Zero Load Power A E S: 7 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 55, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 35 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 60 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 572 mm
Width: 277 mm
Depth: 147 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 1741
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max App Feedin Power: 3, 000 VA
Max Efficiency: 93 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 546 mm
Width: 275 mm
Depth: 147 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 100 A
Max Ac Input Current: 100 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Cont Power V A25: 8, 000 VA
Cont Power W25: 6, 400 W
Cont Power W40: 5, 500 W
Cont Power W65: 4, 000 W
Peak Power Rating: 15, 000 W
Max App Feedin Power: 8, 000 VA
Max Efficiency: 95 %
Zero Load Power: 29 W
Zero Load Power A E S: 19 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 110 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 2, 000 m
A C Connection Terminal Type: M6 bolts
Battery Connection Terminal Type: M8 bolts (two for positive and two for negative connection)
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 42 kg
Height: 642 mm
Width: 363 mm
Depth: 206 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
A C Input Voltage Range1: [ 187, 265 ] VAC
Frequency Select: 50Hz
Transfer Switch Current Rating: 32 A
Max Ac Input Current: 32 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 230 VAC
A C Output Frequency: 50 Hz
Short Name: 4k
Cont Power W25: 3, 400 W
Cont Power W40: 3, 100 W
Cont Power W65: 2, 600 W
Peak Power Rating: 6, 000 W
Max App Feedin Power: 3, 400 W
Max Efficiency: 93 %
Zero Load Power: 18 W
Zero Load Power A E S: 11 W
Zero Load Power Search: 4 W
A C Input Voltage Range: [ 187, 265 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 160 A
Starter Battery Charge Output: 1
Starter Battery Charge Current: 4 A
Temperature Sensor: Included
Auxiliary Output: 1
External Ac Current Sensor: 50A or 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
Max Altitude: 4, 000 m
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts (two for positive and two for negative connection)
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP21
Weight: 22 kg
Height: 576 mm
Width: 276 mm
Depth: 164 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Anti Islanding Standard: Please consult the certificates on our website
Ups Standard: Please consult the certificates on our website
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 93 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 578 mm
Width: 277 mm
Depth: 148 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 24 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 19, 33 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 94 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 55, 65 ] Hz
Charge Voltage Absorption: 28.8 VDC
Charge Voltage Float: 27.6 VDC
Charge Voltage Storage: 26.4 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Starter Battery Charge Output
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 536 mm
Width: 277 mm
Depth: 147 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 95 %
Zero Load Power: 11 W
Zero Load Power A E S: 7 W
Zero Load Power Search: 2 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 55, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 35 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 572 mm
Width: 277 mm
Depth: 147 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 12 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 50 A
Max Ac Input Current: 50 A
D C Input Voltage Range: [ 9.5, 17 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 3, 000 VA
Cont Power W25: 2, 400 W
Cont Power W40: 2, 200 W
Cont Power W65: 1, 700 W
Peak Power Rating: 5, 500 W
Max Efficiency: 93 %
Zero Load Power: 13 W
Zero Load Power A E S: 9 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 55, 65 ] Hz
Charge Voltage Absorption: 14.4 VDC
Charge Voltage Float: 13.8 VDC
Charge Voltage Storage: 13.2 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 120 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 13 mm² (6 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 19 kg
Height: 578 mm
Width: 277 mm
Depth: 148 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-2-29, EN-IEC 60335-1
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 95 A
Max Ac Input Current: 95 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max Efficiency: 96 %
Zero Load Power: 15 W
Zero Load Power A E S: 10 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 55, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 60 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 35 mm² (2 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 32 kg
Height: 676 mm
Width: 330 mm
Depth: 164 mm
Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, CSA C22.2 107.1-16
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Battery Voltage Nominal: 48 V
Power Control: 1
Power Assist: 1
Parallel Operation: 1
Three Phase Operation: 1
Number Ac Inputs: 1
Transfer Switch Current Rating: 95 A
Max Ac Input Current: 95 A
D C Input Voltage Range: [ 38, 66 ] VDC
A C Output Voltage: 120 VAC
A C Output Frequency: 60 Hz
Cont Power V A25: 5, 000 VA
Cont Power W25: 4, 000 W
Cont Power W40: 3, 700 W
Cont Power W65: 3, 000 W
Peak Power Rating: 9, 000 W
Max Efficiency: 96 %
Zero Load Power: 15 W
Zero Load Power A E S: 10 W
Zero Load Power Search: 3 W
A C Input Voltage Range: [ 90, 140 ] VAC
A C Input Frequency Range: [ 45, 65 ] Hz
Charge Voltage Absorption: 57.6 VDC
Charge Voltage Float: 55.2 VDC
Charge Voltage Storage: 52.8 VDC
Charge Algorithm: Adaptive, 4-stage
Maximum Battery Charge Current: 70 A
Temperature Sensor: Included
Number Ac Outputs: 2
Auxiliary Output: 1
External Ac Current Sensor: 100A (optional)
Programmable Relay: AC rating: 120V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections: Output short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Communication Port: VE.Bus
Communication Port General: 1
Remote Terminal: On / Off / Charger only
Computer Programming: 1
Operating Temp Range: [ -40, 65 ] °C
Fan Assist Cooling: 1
Max Humidity: 95 %
A C Connection Terminal Type: Screw terminals 35 mm² (2 AWG)
Battery Connection Terminal Type: M8 bolts
Remote Terminal Type: Screw terminal two pole
Relay Terminal: Screw terminal 3-pole
Vebus Terminal Type: Two RJ45 terminals
Material: Steel
Colour: Blue (RAL 5012)
Protection Category: IP22
Weight: 32 kg
Height: 676 mm
Width: 330 mm
Depth: 164 mm
Safety: CSA C22.2 107.1-16, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 1741 (pending)
Emission Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3

← Volver a productos Victron
