SmartShunt

SKU principal: SHU050150050

SmartShunt

The SmartShunt is an all-in-one battery monitor,
only without a display. Your phone acts as the display. The SmartShunt connects via Bluetooth to the VictronConnect app on your phone (or tablet) and you can conveniently read out all monitored battery parameters,
like state of charge,
time to go,
historical information and much more. Alternatively the SmartShunt can be connected and be read by a GX device. Connection to the SmartShunt is made via a VE.Direct cable. The SmartShunt is a good alternative for a BMV battery monitor,
especially for systems where battery monitoring is needed but less wiring and clutter is wanted. The SmartShunt is equipped with Bluetooth,
a VE.Direct port and a connection that can be used for: monitoring a second battery,
midpoint monitoring or a temperature sensor.

Códigos SKU

SHU050150050 SHU050210050 SHU050220050 SHU065150050 SHU065210050 SHU065220050 SHU067150050 SHU067210050 SHU067220050 SHU050130050 SHU065130050 SHU050150150

DATOS DEL FABRICANTE

Especificaciones técnicas

Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 300 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 10 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Shunt Connection Terminals: M8 bolts
Colour: Black
Protection Category: IP21
Weight: 0.24 kg
Height: 44 mm
Width: 120 mm
Depth: 44 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 300 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.7, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 10 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Ve Direct Cable: 1.5m cable with a VE.Direct socket. Note that a (not included) VE.Direct cable is needed to connect a GX device
Shunt Connection Terminals: M8 bolts
Protection Category: IP65
Weight: 0.32 kg
Height: 44 mm
Width: 120 mm
Depth: 38 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery midpoint deviation, Starter battery voltage, Battery state of charge percentage
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 500 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 10 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Ve Direct Cable: 1.5m cable with a VE.Direct socket. Note that a (not included) VE.Direct cable is needed to connect a GX device
Shunt Connection Terminals: M10 bolts
Protection Category: IP65
Weight: 0.42 kg
Height: 46 mm
Width: 120 mm
Depth: 54 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 1, 000 A
Battery Capacity Measurement Range: [ -∞, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -∞, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Programmable Relay: -1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.1 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: ± 0.3 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 20 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Ve Direct Cable: 1.5m cable with a VE.Direct socket. Note that a (not included) VE.Direct cable is needed to connect a GX device
Shunt Connection Terminals: M10 bolts
Protection Category: IP65
Weight: 1.22 kg
Height: 68 mm
Width: 168 mm
Depth: 75 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 2, 000 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 40 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Ve Direct Cable: 1.5m cable with a VE.Direct socket. Note that a (not included) VE.Direct cable is needed to connect a GX device
Shunt Connection Terminals: M10 bolts
Protection Category: IP65
Weight: 2.22 kg
Height: 68 mm
Width: 168 mm
Depth: 100 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 1, 000 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Programmable Relay: -1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 20 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Shunt Connection Terminals: M10 bolts
Protection Category: IP21
Weight: 1 kg
Height: 68 mm
Width: 168 mm
Depth: 75 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage, Load output Current
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 2, 000 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 40 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Shunt Connection Terminals: M10 bolts
Protection Category: IP21
Weight: 2 kg
Height: 68 mm
Width: 168 mm
Depth: 100 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage, Load output Current
Data Retention Period: 46 d
Supply Voltage Range: [ 6.5, 70 ] VDC
Current Rating: 500 A
Battery Capacity Measurement Range: [ 1, 9, 999 ] Ah
Current Draw: 1 mA
Input Voltage Measurement Range Auxiliary Battery: [ 6.5, 70 ] VDC
Operating Temperature Range: [ -40, 50 ] °C
Aux Input Fo Auxiliary Battery Voltage: 1
Temperature Sensor: Optional (ASS000100000 - Temp. sensor for BMV)
Temperature Measurement Range: [ -20, 50 ] °C
Communication Port: VE.Direct
Bluetooth: 1
Display
Visual Alarm On Device
Audible Alarm On Device
Current Measurement Resolution: 0.01 A
Voltage Measurement Resolution: 0.01 V
Capacity Measurement Resolution: 0.1 Ah
State Of Charge Measurement Resolution: 0.1 %
Time To Go Measurement Resolution: 1 min
Temperature Resolution: 1 °C
Measurement Accuracy: 0.4 %
Current Measurement Accuracy: 0.4 %
Current Measurement Offset: 10 mA
Voltage Measurement Accuracy: 0.3 %
Positive Cable: 1.5m cable with 1A fuse
Aux Cable: 1.5m cable with 1A fuse
Shunt Connection Terminals: M10 bolts
Protection Category: IP21
Weight: 0.32 kg
Height: 46 mm
Width: 120 mm
Depth: 54 mm
Front Diameter: 63 mm
Body Diameter: 52 mm
Body Depth: 31 mm
Safety: EN 60335-1
Emisison Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive Directive: EN 50498
Data Stored: Battery voltage, Battery current, Battery temperature, Battery state of charge percentage, Battery midpoint deviation, Starter battery voltage
Data Retention Period: 46 d

← Volver a productos Victron
