Cyrix Battery Combiners

SKU principal: CYR010120011

The Cyrix Battery Combiner is a microprocessor controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged),
and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so that the output voltage of alternators or battery chargers does not need to be increased.

Códigos SKU

CYR010120011 CYR010120011R CYR010230010 CYR010230010R CYR010400000 CYR020400000 CYR010120450 CYR020120450 CYR010120430 CYR020120430 CYR010120412 CYR010230450 CYR020230450 CYR010230430 CYR020230430 CYR010230412

DATOS DEL FABRICANTE

Especificaciones técnicas

Nominal Battery Voltage: 12V or 24V
Continuous Current1224: 120 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Protection Category: IP54
Weight: 0.11 kg
Height: 46 mm
Width: 46 mm
Depth: 80 mm
Nominal Battery Voltage: 12V or 24V
Continuous Current1224: 120 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Protection Category: IP54
Weight: 0.11 kg
Height: 64 mm
Width: 64 mm
Depth: 80 mm
Nominal Battery Voltage: 24V or 48V (automatic detection)
Continuous Current1224: 120 A
Continuous Current48: 40 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Protection Category: IP54
Weight: 0.11 kg
Height: 64 mm
Width: 64 mm
Depth: 80 mm
Nominal Battery Voltage: 24V or 48V (automatic detection)
Continuous Current1224: 230 A
Continuous Current48: 80 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Led Status Indication: 1
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current1224: 230 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Led Status Indication: 1
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current: 120 A
Cranking Current Rating: 180 A
Connect Voltage: From 13 to 13.8V and 26 to 27.6V with intelligent trend detection
Disconnect Voltage: From 11 to 1.8V and 22 to 25.7V with intelligent trend detection
Current Consumption Open: 4 mA
Current Consumption Closed12: 220 mA
Current Consumption Closed24: 120 mA
Start Assist: Yes (Cyrix remains engaged during 30 seconds)
Battery Terminals: M6 bolts
Start Assist Terminal: Faston tab 6.3 mm
Battery Negative Terminal: Faston tab 6.3 mm
Protection Category: IP54
Weight: 0.11 kg
Height: 46 mm
Width: 46 mm
Depth: 89 mm
Continuous Current: 230 A
Cranking Current Rating: 500 A
Connect Voltage: From 13 to 13.8V and 26 to 27.6V with intelligent trend detection
Disconnect Voltage: From 11 to 1.8V and 22 to 25.7V with
Current Consumption Open: 4 mA
Current Consumption Closed12: 320 mA
Current Consumption Closed24: 180 mA
Start Assist: Yes (Cyrix remains engaged during 30 seconds)
Battery Terminals: M8 bolts
Start Assist Terminal: Two pole connector
Battery Negative Terminal: Two pole connector
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current: 230 A
Cranking Current Rating: 500 A
Connect Voltage: From 13 to 13.8V and 26 to 27.6V with intelligent trend detection
Disconnect Voltage: From 11 to 1.8V and 22 to 25.7V with
Current Consumption Open: 4 mA
Current Consumption Closed12: 230 mA
Current Consumption Closed24: 180 mA
Start Assist: Yes (Cyrix remains engaged during 30 seconds)
Battery Terminals: M8 bolts
Start Assist Terminal: Two pole connector
Battery Negative Terminal: Two pole connector
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Input Voltage Range: [ 8, 36 ] V
Continuous Current: 400 A
Peak Current Rating: 2, 000 A
Connect Profiles: See table on website
Over Voltage Disconnect: 16V @12V / 32V @24V
Current Consumption Open: 4 mA
Start Assist: Yes, 30 seconds
Remote Monitoring Switch: 1
Led Status Indication: 1
Weight: 0.9 kg
Height: 78 mm
Width: 102 mm
Depth: 110 mm
Nominal Battery Voltage: 24V or 48V (automatic detection)
Input Voltage Range: [ 16, 72 ] V
Continuous Current: 400 A
Peak Current Rating: 2, 000 A
Connect Profiles: See table on website
Over Voltage Disconnect: 32V @24V / 64V @48V
Current Consumption Open: 4 mA
Start Assist: Yes, 30 seconds
Remote Monitoring Switch: 1
Led Status Indication: 1
Weight: 0.9 kg
Height: 78 mm
Width: 102 mm
Depth: 110 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current1224: 230 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Led Status Indication: 1
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 24V or 48V (automatic detection)
Continuous Current1224: 230 A
Continuous Current48: 80 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Led Status Indication: 1
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current: 120 A
Cranking Current Rating: 180 A
Connect Voltage: From 13 to 13.8V and 26 to 27.6V with intelligent trend detection
Disconnect Voltage: From 11 to 1.8V and 22 to 25.7V with
Current Consumption Open: 4 mA
Current Consumption Closed12: 220 mA
Current Consumption Closed24: 120 mA
Start Assist: Yes (Cyrix remains engaged during 30 seconds)
Battery Terminals: M6 bolts
Start Assist Terminal: Faston 6.3 mm
Battery Negative Terminal: Faston 6.3 mm
Protection Category: IP54
Weight: 0.11 kg
Height: 46 mm
Width: 46 mm
Depth: 80 mm
Nominal Battery Voltage: 24V or 48V (automatic detection)
Continuous Current1224: 120 A
Continuous Current48: 40 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Protection Category: IP54
Weight: 0.11 kg
Height: 46 mm
Width: 46 mm
Depth: 80 mm
Nominal Battery Voltage: 12V or 24V (automatic detection)
Continuous Current1224: 230 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Led Status Indication: 1
Control Cable Included: 1
Protection Category: IP54
Weight: 0.27 kg
Height: 65 mm
Width: 100 mm
Depth: 50 mm
Nominal Battery Voltage: 12V or 24V
Continuous Current1224: 120 A
Connect Profiles: See our website
Control Input: The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
Current Consumption Open: 4 mA
Protection Category: IP54
Weight: 0.11 kg
Height: 64 mm
Width: 64 mm
Depth: 80 mm
