- Battery Voltage Auto Select
- 12V / 24V (
- Rated Charge Current
- 30 A
- Nominal P Vpower12 V
- 440 W
- Nominal P Vpower24 V
- 880 W
- Charge Voltage Absorption
- 14.4V / 28.8V (adjustable)
- Charge Voltage Float
- 13.8V / 27.6V (adjustable)
- Charge Algorithm
- Multi-stage adaptive (adjustable)
- Temperature Compensation12 V
- -16 mV/°C
- Temperature Compensation24 V
- -32 mV/°C
- Max Efficiency
- 98 %
- Self Consumption
- 12V: 30mA,
24V: 20mA
- Max P V Open Circuit Voltage
- 100 V
- Start Up P V D C Voltage
- The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V
- Number Of Trackers
- 1
- Max P V Short Circuit Current
- 35 A
- Protections
- Excessive temperature,
PV reverse polarity
- Operating Temp Range
- [
-30,
60
] °C
- Max Humidity
- 95 %
- Bluetooth
- Data Communication
- VE.Direct
- Battery Connection Terminal Type
- Screw terminals 16 mm² (6 AWG)
- P V Connection Terminal Type
- Screw terminals 16 mm² (6 AWG)
- Colour
- Blue (RAL 5012)
- Protection Category
- IP22 (connection area),
IP43 (electronic components)
- Weight
- 1.3 kg
- Height
- 130 mm
- Width
- 186 mm
- Depth
- 70 mm
- Safety
- CSA C22.2,
UL 1741,
EN-IEC 62109-1
- Battery Voltage Auto Select
- 12V / 24V (
- Rated Charge Current
- 50 A
- Nominal P Vpower12 V
- 700 W
- Nominal P Vpower24 V
- 1,
400 W
- Charge Voltage Absorption
- 14.4V / 28.8V (adjustable)
- Charge Voltage Float
- 13.8V / 27.6V (adjustable)
- Charge Algorithm
- Multi-stage adaptive (adjustable)
- Temperature Compensation12 V
- -16 mV/°C
- Temperature Compensation24 V
- -32 mV/°C
- Max Efficiency
- 98 %
- Self Consumption
- 12V: 30mA,
24V: 20mA
- Max P V Open Circuit Voltage
- 100 V
- Start Up P V D C Voltage
- The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V
- Number Of Trackers
- 1
- Max P V Short Circuit Current
- 60 A
- Protections
- Excessive temperature,
PV reverse polarity
- Operating Temp Range
- [
-30,
60
] °C
- Max Humidity
- 95 %
- Data Communication
- VE.Direct
- Battery Connection Terminal Type
- Screw terminals 16 mm² (6 AWG)
- P V Connection Terminal Type
- Screw terminals 16 mm² (6 AWG)
- Colour
- Blue (RAL 5012)
- Protection Category
- IP22 (connection area),
IP43 (electronic components)
- Weight
- 1.3 kg
- Height
- 130 mm
- Width
- 186 mm
- Depth
- 70 mm
- Safety
- CSA C22.2,
EN-IEC 62109-1,
UL 1741
