BlueSolar Panels

SKU principal: SCA000100000

BlueSolar Panels

<ul><li>Low voltage-temperature coefficient enhances high-temperature operation.</li><li>Exceptional low-light performance and high sensitivity to light across the entire solar spectrum.</li><li>25-Year limited warranty on power output and performance.</li><li>5-Year Limited warranty on materials and workmanship.</li><li>Sealed,
waterproof,
multifunctional junction box gives high level of safety.</li><li>High performance bypass diodes minimize the power drop caused by shade.</li><li>Advanced EVA (Ethylene Vinyl Acetate) encapsulation system with triple-layer back sheet meets the most stringent safety requirements for high-voltage operation.</li><li>A sturdy,
anodized aluminium frame allows modules to be easily roof-mounted with a variety of standard mounting systems.</li><li>Highest quality,
high-transmission tempered glass provides enhanced stiffness and impact resistance.</li><li>Pre wired quick-connect system with PV-ST01 connectors. </li></ul>

Códigos SKU

SCA000100000 SCA000300000 SCA000500000 SCA000100100 SCA000300100 SCA000500100 SCA001000100 SCA002000100 SCA500100000 SCA500200000 SCA520300000 SCA520500000 SPP041751200 SPP040201200 SPM040201200 SPM040551200 SPM041751200 SPP040301200 SPP040601200 SPP040901200 SPM040401200 SPM040901200 SPM042152400 SPM040301200 SPP040451200 SPP042702000 SPM041401200 SPM043602402 SPM043052002 SPM041151202 SPP041151202 SPP043302402 SPM042152402 SPM041501200 SPM041851200 SPM041301200 SPP041301200 SPM040303603 SPM040553603 SPM040953003 SPM041303603 SPM041903903 SPM043456803 SPM040203603 SPM043657203 SPM042855603 SPM042357203 SPM040553604 SPM040953004 SPM042357204 SPM040303604 SPM040203604 SPM040403604 SPM042855604

DATOS DEL FABRICANTE

Especificaciones técnicas

Nominal Power: 20 W
Max Power Voltage: 18.5 V
Max Power Current: 1.09 A
Open Circuit Voltage: 22.6 V
Short Circuit Current: 1.49 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0805
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 1.9 kg
Height: 440 mm
Width: 350 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 380
Nominal Power: 90 W
Max Power Voltage: 19.6 V
Max Power Current: 4.59 A
Open Circuit Voltage: 24.06 V
Short Circuit Current: 5.03 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0801
P V Cable Connection Type: MC4
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 6.1 kg
Height: 780 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 72
Nominal Power: 130 W
Max Power Voltage: 18.64 V
Max Power Current: 6.98 A
Open Circuit Voltage: 22.83 V
Short Circuit Current: 7.35 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0808-1
P V Cable Connection Type: MC4
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 9.1 kg
Height: 1, 200 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 36
Nominal Power: 130 W
Max Power Voltage: 18.64 V
Max Power Current: 6.98 A
Open Circuit Voltage: 22.83 V
Short Circuit Current: 7.35 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0808-1
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 9.1 kg
Height: 1, 200 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 36
Nominal Power: 185 W
Max Power Voltage: 19.68 V
Max Power Current: 9.41 A
Open Circuit Voltage: 24.11 V
Short Circuit Current: 9.91 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0808
P V Cable Connection Type: MC4
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 11 kg
Height: 1, 485 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 48
Nominal Power: 305 W
Max Power Voltage: 32.5 V
Max Power Current: 9.38 A
Open Circuit Voltage: 39.7 V
Short Circuit Current: 10.27 A
Cell Type: Polycrystalline
Number Of Cells In Series: 60
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-JB002
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 19 kg
Height: 1, 658 mm
Width: 1, 002 mm
Depth: 35 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 42
Nominal Power: 360 W
Max Power Voltage: 38.4 V
Max Power Current: 9.38 A
Open Circuit Voltage: 47.4 V
Short Circuit Current: 10.24 A
Cell Type: Polycrystalline
Number Of Cells In Series: 72
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-JB002
P V Cable Connection Type: 900 mm
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 23 kg
Height: 1, 980 mm
Width: 1, 002 mm
Depth: 40 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 37
Nominal Power: 20 W
Max Power Voltage: 18.4 V
Max Power Current: 1.09 A
Open Circuit Voltage: 21.96 V
Short Circuit Current: 1.18 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0805
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 1.9 kg
Height: 440 mm
Width: 350 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 380
Nominal Power: 30 W
Max Power Voltage: 18.2 V
Max Power Current: 1.66 A
Open Circuit Voltage: 21.8 V
Short Circuit Current: 1.8 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0806
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 2.8 kg
Height: 655 mm
Width: 350 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 240
Nominal Power: 45 W
Max Power Voltage: 19.1 V
Max Power Current: 2.36 A
Open Circuit Voltage: 22.9 V
Short Circuit Current: 2.55 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 2.55 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0806
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 3.1 kg
Height: 425 mm
Width: 668 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 200
Nominal Power: 60 W
Max Power Voltage: 19.3 V
Max Power Current: 3.12 A
Open Circuit Voltage: 23.1 V
Short Circuit Current: 3.37 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0801
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 4 kg
Height: 545 mm
Width: 668 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 140
Nominal Power: 90 W
Max Power Voltage: 19.5 V
Max Power Current: 4.61 A
Open Circuit Voltage: 23.44 V
Short Circuit Current: 4.98 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0801
P V Cable Connection Type: 900 mm
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 6.1 kg
Height: 780 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 72
Nominal Power: 175 W
Max Power Voltage: 18.3 V
Max Power Current: 9.56 A
Open Circuit Voltage: 21.9 V
Short Circuit Current: 10.24 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0808
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 12 kg
Height: 1, 485 mm
Width: 668 mm
Depth: 30 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 48
Nominal Power: 270 W
Max Power Voltage: 31.7 V
Max Power Current: 8.52 A
Open Circuit Voltage: 38.04 V
Short Circuit Current: 9.21 A
Cell Type: Polycrystalline
Number Of Cells In Series: 60
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-JB002
P V Cable Connection Type: 900 mm
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 18.4 kg
Height: 1, 640 mm
Width: 992 mm
Depth: 35 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 42
Nominal Power: 30 W
Max Power Voltage: 18.7 V
Max Power Current: 1.61 A
Open Circuit Voltage: 22.87 V
Short Circuit Current: 1.76 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0805
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 2.2 kg
Height: 560 mm
Width: 350 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 260
Nominal Power: 55 W
Max Power Voltage: 18.8 V
Max Power Current: 2.94 A
Open Circuit Voltage: 22.9 V
Short Circuit Current: 3.22 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0806
P V Cable Connection Type: No Cable
Frame Material: Aluminium
Weight: 4 kg
Height: 545 mm
Width: 668 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 140
Nominal Power: 215 W
Max Power Voltage: 40.1 V
Max Power Current: 5.36 A
Open Circuit Voltage: 46.01 V
Short Circuit Current: 5.65 A
Cell Type: Polycrystalline
Number Of Cells In Series: 72
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0701
P V Cable Connection Type: MC4
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 11.7 kg
Height: 1, 580 mm
Width: 705 mm
Depth: 35 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 42
Nominal Power: 330 W
Max Power Voltage: 37.3 V
Max Power Current: 8.86 A
Open Circuit Voltage: 44.72 V
Short Circuit Current: 9.57 A
Cell Type: Polycrystalline
Number Of Cells In Series: 72
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-JB002
P V Cable Connection Type: 900 mm
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 23 kg
Height: 1, 980 mm
Width: 1, 002 mm
Depth: 40 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 37
Nominal Power: 40 W
Max Power Voltage: 48.3 V
Max Power Current: 2.19 A
Open Circuit Voltage: 22.45 V
Short Circuit Current: 2.4 A
Cell Type: Polycrystalline
Number Of Cells In Series: 36
Max System Voltage: 1, 000 V
Temp Coefficient Isc M P P: -0.45 %/°C
Temp Coefficient Isc Voc: -0.35 %/°C
Temp Coefficient Isc: 0.04 %/°C
Operating Temp Range: [ -40, 85 ] °C
Surface Max Load Capacity: 200 kg/m²
Allowable Hail Load Speed: 23 m/s
Allowable Hail Load Weight: 7.53 g
P V Output Tolerance: 3 %
Junction Box Type: PV-LH0806
P V Cable Connection Type: No Cable
P V Cable Length: 900 mm
Frame Material: Aluminium
Weight: 3.1 kg
Height: 425 mm
Width: 668 mm
Depth: 25 mm
Product Warranty: 5 y
Warranty90 Output: 10 y
Warranty80 Output: 10 y
Smallest Packaging Unit: 1
Number Of Panels Per Pallet: 200

← Volver a productos Victron
