GX Touch 50 & GX Touch 70

SKU principal: BPP900455050

<p>The GX Touch 50 and GX Touch 70 are display accessories for our <a href="/panel-systems-remote-monitoring/cerbo-gx">Cerbo GX</a>. The five inch and seven inch touch screen displays give an instant overview of your system and allow to adjust settings in the blink of an eye. Simply connected to the Cerbo GX with one cable,
Their super slim waterproof design,
top-mountable setup and simple installation bring a lot of flexibility when creating a crisp and clean dashboard. </p><p><a href="https://www.youtube.com/watch?v=3wheKaU2_qw&feature=youtu.be">Watch the new video</a> that explains all there is to know about installing the new Cerbo GX & GX Touch 50.</p>

Códigos SKU

BPP900455050 BPP900455070 BPP900455150 BPP900455170

DATOS DEL FABRICANTE

Especificaciones técnicas

Display Resolution: 800 xx 480
Mounting: Top/wall mount with included mounting accessories
Protection Cover: Included with every GX Touch from serial number HQ2242 Can also be purchased individually: Part # BPP900462050: GX Touch 50 protection cover
Cable Length: 2 m
Protection Category: IP54 (without connectors)
Height: 87 mm
Width: 128 mm
Depth: 12.4 mm
Display Resolution: 800 xx 480
Mounting: Flush mount or embossed (totally flush)
Protection Cover: No
Cable Length: 2 m
Protection Category: IP65 (when installed with included rubber gasket)
Height: 94 mm
Width: 136 mm
Depth: 10 mm
Display Resolution: 1024 x 600
Mounting: Top/wall mount with included mounting accessories
Protection Cover: Included with every GX Touch from serial number HQ2242 Can also be purchased individually: Part # BPP900462070: GX Touch 70 protection cover
Cable Length: 2 m
Protection Category: IP54 (without connectors)
Height: 113 mm
Width: 176 mm
Depth: 13.5 mm
