Fuses & fuse holders

SKU principal: CIP000050001

Besides an assortment of ANL,
MIDI and MEGA fuses,
we feature three different types of fuse holders: <ul><li>Simple single fuse holders for each of above fuse types. </li><li>A six-way fuse holder,
MEGA fuses only. </li><li>Modular single fuse holders,
for MEGA fuses only. With an optional busbar accessory to efficiently connect multiple fuses together. </li></ul> For a full list of available parts,
refer to the price list. For more technical information,
see the respective datasheets. Besides above fuse holders,
we also have the Lynx Power In and the Lynx Distributor,
part of the Lynx 1000 Amp distribution system. See the <a href="https://www.victronenergy.com/dc-distribution-systems">DC Distribution section on our website</a>.

Códigos SKU

CIP000050001 CIP132100010 CIP132150010 CIP132200010 CIP133100010 CIP000100001 CIP100200100 CIP100400060 CIP100400070 CIP136060010 CIP136080010 CIP136100010 CIP136125010 CIP136150010 CIP136175010 CIP136200010 CIP136225010 CIP136250010 CIP136300010 CIP136400010 CIP136500010 CIP137125010 CIP137200010 CIP137250010 CIP137300010 CIP106100000 CIP142400000 CIP142500000 CIP140325000 CIP133060010 CIP132060010 CIP132080010 CIP133030010 CIP133040010 CIP133050010 CIP133080010 CIP050060000 CIP142300000 CIP132125010 CIP138300020 CIP143400020 CIP143300020 CIP138125020 CIP138080020 CIP138100020 CIP138150020 CIP138175020 CIP138225020 CIP138400020 CIP138500020 CIP134080020 CIP138040020 CIP138060020 CIP138200020 CIP134040020 CIP134060020 CIP134030020 CIP134050020 CIP134100020 CIP143500020 CIP138250020

DATOS DEL FABRICANTE

Especificaciones técnicas

Current Rating: 200 A
Voltage Rating: 32 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.25 mΩ
Current Rating: 100 A
Voltage Rating: 58 V
Approximate Voltage Drop: 70 mV
Cold Resistance: 0.45 mΩ
Current Rating: 200 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.253 mΩ
Current Rating: 50 A
Voltage Rating: 58 V
Approximate Voltage Drop: 65 mV
Cold Resistance: 1 mΩ
Current Rating: 400 A
Voltage Rating: 80 V
Approximate Voltage Drop: 125 mV
Cold Resistance: 0.16 mΩ
Current Rating: 150 A
Voltage Rating: 32 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.3 mΩ
Current Rating: 250 A
Voltage Rating: 58 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.2 mΩ
Current Rating: 60 A
Voltage Rating: 80 V
Approximate Voltage Drop: 135 mV
Cold Resistance: 1.459 mΩ
Current Rating: 100 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.716 mΩ
Current Rating: 150 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.332 mΩ
Current Rating: 175 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.282 mΩ
Current Rating: 225 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.208 mΩ
Current Rating: 225 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.235 mΩ
Current Rating: 200 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.282 mΩ
Current Rating: 60 A
Voltage Rating: 80 V
Approximate Voltage Drop: 135 mV
Cold Resistance: 1.017 mΩ
Busbar Material: Tinned copper
Busbar Dimensions: 3mm x 18mm
Cover Material: ABS
Height: 46 mm
Width: 90 mm
Depth: 23.5 mm
Current Rating: 40 A
Voltage Rating: 80 V
Approximate Voltage Drop: 135 mV
Cold Resistance: 1.459 mΩ
Current Rating: 300 A
Voltage Rating: 80 V
Approximate Voltage Drop: 125 mV
Cold Resistance: 0.18 mΩ
Current Rating: 500 A
Voltage Rating: 80 V
Approximate Voltage Drop: 100 mV
Cold Resistance: 0.25 mΩ
Current Rating: 80 A
Voltage Rating: 58 V
Approximate Voltage Drop: 70 mV
Cold Resistance: 0.42 mΩ
Width: 94 mm
Depth: 37 mm
Max Current: 250 A
Max Voltage: 70 V
Busbar Material: Tin plated copper
Busbar Dimensions: 3mm x 18mm
Terminal Diameter1: 8 mm
Terminal Height1: 14 mm
Terminal Material: Galvanised steel
Hex Nut Material: Galvanised steel
Base Material: polycarbonate
Base Colour: Black
Base Fire Rating: UL 94 V-0
Cover Material: ABS
Cover Colour: Clear
Cover Fire Rating: UL 94 HB
Weight: 0.45 kg
Height: 51 mm
Width: 182 mm
Depth: 88 mm
Max Current: 1, 500 A
Busbar Material: Tinned copper
Busbar Dimensions: 5mm x 40mm
Terminal Diameter1: 8 mm
Height: 5 mm
Width: 180 mm
Depth: 40 mm
Max Current: 1, 500 A
Busbar Material: Tinned copper
Busbar Dimensions: 5mm x 40mm
Terminal Diameter1: 8 mm
Height: 5 mm
Width: 240 mm
Depth: 40 mm
Current Rating: 30 A
Voltage Rating: 58 V
Approximate Voltage Drop: 65 mV
Cold Resistance: 2 mΩ
Current Rating: 225 A
Voltage Rating: 32 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.22 mΩ
Current Rating: 250 A
Voltage Rating: 32 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.2 mΩ
Current Rating: 300 A
Voltage Rating: 32 V
Approximate Voltage Drop: 80 mV
Cold Resistance: 0.17 mΩ
Current Rating: 125 A
Voltage Rating: 80 V
Approximate Voltage Drop: 110 mV
Cold Resistance: 0.868 mΩ
Current Rating: 400 A
Voltage Rating: 32 V
Approximate Voltage Drop: 70 mV
Cold Resistance: 0.13 mΩ
Current Rating: 500 A
Voltage Rating: 32 V
Approximate Voltage Drop: 70 mV
Cold Resistance: 0.1 mΩ
Busbar Material: Tinned copper
Busbar Dimensions: 3mm x 18mm
Cover Material: ABS
Height: 25 mm
Width: 52 mm
Depth: 29.5 mm
Current Rating: 60 A
Voltage Rating: 32 V
Approximate Voltage Drop: 70 mV
Cold Resistance: 0.9 mΩ
Current Rating: 80 A
Voltage Rating: 32 V
Approximate Voltage Drop: 60 mV
Cold Resistance: 0.55 mΩ
Current Rating: 100 A
Voltage Rating: 32 V
Approximate Voltage Drop: 60 mV
Cold Resistance: 0.3 mΩ
Current Rating: 125 A
Voltage Rating: 60 V
Approximate Voltage Drop: 60 mV
Cold Resistance: 0.3 mΩ
